Select tool ordering of fields. Is there a way to keep the fields from changing order?

[wonka1234]

Hi,

I run my workflow on a server. and different months are chosen each time (see photo)

now i ran it locally and before my select tool the fields are in order.

After they the select tool ran , they get shifted to the end (some of them)

why is this happening? Is there a way to keep the months chosen grouped together?

[cjaneczko]

You'll likely need a macro. I have this issue with a workflow I run monthly where the fields would get out of order. Take a look at the below macro flow. It uses a Field Info tool with a record ID tool to set the order of the fields. Then it concatenates the Record order to the Field names and cross tabs it. Once Cross tabbed it uses the Dynamic Rename tool to rename the column headers in the appropriate order and removes the Sort Order prefix.

Ignore the Lower Input tool and Union as I am also grabbing field names from another file to add into this one.

You can also try out the CReW Field Sort macro.

http://www.chaosreignswithin.com/2014/08/field-sort-macro.html

[wonka1234]

@cjaneczko

posting specific example -

problems:

1) 20221031 should come before 202211

2) Is it possible to insert the date columns between "folder" and "test" dynamically?

ie from

201031

folder

test

to

folder

20221031

test

[cjaneczko]

To solve the 20221031 issue, add a Record ID tool after your filter and concatenate the Record_ID to the Name field. This will preserve the field order. As for putting the 20221031 between the Folder and Test, will 2021031 always be the field name or is it dynamic and can change?

[wonka1234]

@cjaneczko  ok thanks! u solved my issue #1!

20221031 can change.. its dynamic..  ie

my output is this

20221031

202211

202212

etc

etc

etc

etc

col 1

col 2

col 3

could be any dates in the first 3 columns there.

Need a way to insert it affter a certain column...

[cjaneczko]

Which columns are always first and static? Where do you need the 3 date columns? And what is after those 3 Dynamic Date columns. You will likely need a couple field info tools and some Multi Row Formulas to accomplish it. You'll essentially need to create some Record ID's with the multi Row Formula. The Record ID can capture the fields that will always be static. Then use the Multi Row formula to create a Record_ID count that starts after the number of fields that are Static. So if you have 4 fields in the front that are static use Record ID to count 1-4. Then use the Multi Row formula to create a Record ID starting from 5 onward. Union all these together to get the fields in the correct order based on the Record ID's and then Cross tab then like you've already done.

You may also need a sample tool to dynamically grab the first three dynamic date records.

[cjaneczko]

Is this the output you are looking for?

[wonka1234]

@cjaneczko  yes that is the output.  not sure if you can alter my workflow to get this...

[cjaneczko · Accepted solution]

See attached.

[wonka1234]

@cjaneczko  thanks! u the man!! testing it more thoroughly now..
