I am a newbie to Alteryx and after a week of looking to solve this problem on my own i realized that I need some help. I am looking to run a process for each file and then have a final output appending all the outcomes of each individual file run. * On my first workflow I need to change the Input Data connection for each file to run, * After some online searching I found out about the batch macros that technically would solve my problem, then I added the Incoming Control Parameter to specify the location of the files I need to process individually and Outcoming Control Parameter with the location for the outputs. * The issue is that the process is bringing all the files at once to process instead of processing one file at a time and output the result, look for the following, process and output…. (Looping the process through all the files). Anyone to help this poor soul? Thanks Macro.yxmc

Looking workflow through each file and append each outcome to final master doc

I am a newbie to Alteryx and after a week of looking to solve this problem on my own i realized that I need some help.

I am looking to run a process for each file and then have a final output appending all the outcomes of each individual file run.

On my first workflow I need to change the Input Data connection for each file to run,
After some online searching I found out about the batch macros that technically would solve my problem, then I added the Incoming Control Parameter to specify the location of the files I need to process individually and Outcoming Control Parameter with the location for the outputs.
The issue is that the process is bringing all the files at once to process instead of processing one file at a time and output the result, look for the following, process and output…. (Looping the process through all the files).

Anyone to help this poor soul?

Thanks

Macro.yxmc

Topic of Interest

Accepted answers

JoeS

Ah, I missed it in your macro first time looking through.

Your action tools aren't quite set up right, and you also had the input tool set to have a wildcard, so that itself will read in all the files.

In the action tool you need to select the part you are wanting to change.

I can see that you are passing in via the control parameter the file name (I do wonder if you want to do the full path?)

You then need to select that part in the action tool in which you want to change, so the first action tool should look like:

You can see I have the file path selected at the top, and then at the bottom I am saying I only want to change "*.xlsx" as that's the file name part.

You'll need to do similar for the output tool. On this note I can see you are actually passing the same value. Do you want each batch to overwrite the file that it has read in?

In my attached workflow and macro I have made a change to rename the output file OrignalName_Output.xlsx.

I have also updated the action tools within the macro.

Hopefully that helps, feel free to ask more questions though!

Macro 2.yxmd

Macro.yxmc

JoeS

In Excel the Input tool needs to know the name of the workbook and the name of the sheet.

For example you input tool has:

C:\Users\DataAnalytics\Desktop\Quidna\*.xlsx|||`Timeline$

The parts at the end, 3 pipes, "|||" denote that the sheet name is then going to follow, "Timeline", the dollar symbol denotes that its a sheet name and not a named range within Excel.

I think you'll need to double check your Action tools are updating the right parts.

You need to have the bit highlighted on the left that you are wanting to change and then the part at the bottom with the string you want to replace.

In both of your action tools this isn't quite lined up right.

All comments

JoeS

@QF

I think you are very close to what you need. I think you will want to add a macro output as well. This will roll them all together and pass the records outside the batch macro.

The other part looks like it is looping OK. Could you attach your workflow as well?

Hi Joe,

Thanks for your help, please find the workflows in the attachment.

The first one "Macro" run successfully but the second one i get the flowing error ' Macro (9) Record #1: Tool #14: You must specify a sheet name.)'

Regards,

Quidna

Macro 2.yxmd

Macro.yxmc
