Overlapping Date Range Report

Hello experts,

I am looking to generate a report that produces overlapping date ranges of projects within a group. I have seen similar topics, but not one that handles 2 different sets of overlaps within a group like this example.

Data
Components	Projects	Start Date	End Date
IT Component 1	Project A	10/1/2024	10/1/2025
IT Component 1	Project B	1/1/2024	12/31/2024
IT Component 2	Project C	1/1/2024	1/31/2025
IT Component 2	Project D	9/15/2024	10/1/2025
IT Component 2	Project E	7/15/2024	1/15/2026
IT Component 2	Project F	11/15/2025	1/15/2026

Desired Result
Components	Projects	Overlap Start	Overlap End
IT Component 1	Project A	10/1/2024	12/31/2024
	Project B
IT Component 2	Project C	7/15/2024	1/31/2025
	Project D
	Project E
	Project E	11/15/2025	1/15/2026
	Project F

Thank you in advance for any help on this.

Datasets

Date Time

Help

Accepted answers

AncientPandaman

@chadosu here my version.

Screenshot 2023-08-16 103439.png

mainly use join for component, then each project is compared to all project within same component.

then use math to reveal the overlap.

Screenshot 2023-08-16 103434.png

and it was hard to merge as you can see project D actually fully overlap by project E. Hence, I output everything.

Screenshot 2023-08-16 103455.png

beside, for your workflow, you can add one multi-row formula, if the date different more than 1 then goto another group then summarize with ID.

config:

Screenshot 2023-08-16 103246.png

result:

Screenshot 2023-08-16 103300.png

Overlap.yxmd

All comments

collinmarchese

Here's a primitive example of how to achieve this. If i had more time I would figure out a way to make this more dynamic but this will give you an idea. Basically creating record for each date between start/end range and joining on dates between the projects to see the overlapping dates, then find min/max of the shared dates. hope this helps.

Overlapping Date Range Report.yxmd

chadosu

I appreciate your input! I have been able to get close with the attached file. My problem is this takes the absolute start and end of Component 2 instead of breaking it apart.

Overlapping Date Range Report.yxmd

AncientPandaman

@chadosu here my version.

Screenshot 2023-08-16 103439.png

mainly use join for component, then each project is compared to all project within same component.

then use math to reveal the overlap.

Screenshot 2023-08-16 103434.png

and it was hard to merge as you can see project D actually fully overlap by project E. Hence, I output everything.

Screenshot 2023-08-16 103455.png

beside, for your workflow, you can add one multi-row formula, if the date different more than 1 then goto another group then summarize with ID.

config:

Screenshot 2023-08-16 103246.png

result:

Screenshot 2023-08-16 103300.png

Overlap.yxmd

chadosu

I believe this is the solution I am after! I realized that in my original desired result, not all overlaps were actually captured, but your solution captures them!

Thank you very much!
